MG
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75.395 | 76.99375 | 42.06875 | 17.4625 | 2.968307 | 3 1/32 | 1 21/32 | 11/16 |
Morris
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 80.9625 | 44.45 | 22 | 3.149606 | 3 3/16 | 1 3/4 | 0.866142 |
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
Bedford M type
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 85.725 | 41.275 | 20.6375 | 3 3/8 | 3 3/8 | 1 5/8 | 13/16 |
4 cyl piston set 1296 for Morris - 15.9h.p. 2513cc Colonial, Z 30cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 44.45 | 94.45625 | 22.225 | 3.149606 | 1 3/4 | 3 23/32 | 7/8 |
6 cyl piston set 3339 for Vauxhall - 16.9h.p. 2048cc Cadet, VY
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 67.5 | 77.7875 | 41.275 | 22.225 | 2.65748 | 3 1/16 | 1 5/8 | 7/8 |
1 cyl piston set 4046 for Villiers - 148cc Longstroke, Two Port, X11C, GY, Two-Stroke with Deflector
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 53 | 91.28125 | 51.59375 | 12.5 | 2.086614 | 3 19/32 | 2 1/32 | 0.492126 |
6 cyl piston set 4823 for Essex - 16.9h.p. 2723cc Terraplane E78
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 67.46875 | 84.1375 | 46.0375 | 19.05 | 2 21/32 | 3 5/16 | 1 13/16 | 3/4 |
4 cyl piston set 5140 for Commer - 14h.p. 15, 20, 25cwt B20 NI
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 92.25 | 51 | 22 | 2.952756 | 3.63189 | 2.007874 | 0.866142 |
4 cyl piston set 5778 for Cadillac - V8 355E, 355D
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 118.665625 | 45.640625 | 22.225 | 3 3/8 | 4 43/64 | 1 51/64 | 7/8 |
4 cyl piston set 7450 for Mercedes - 13.4h.p. 1697cc 170V, 170H M28
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.5 | 79.5 | 38 | 11 | 2.893701 | 3.129921 | 1.496063 | 0.433071 |
4 cyl piston set 7591 for Vulcan - 25.8h.p. Duchess 5VF, 6VF1/2/3 Tipper 5-6 ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 102 | 111.125 | 60.325 | 25.4 | 4.015748 | 4 3/8 | 2 3/8 | 1 |
6 cyl piston set 7672 for Austin - 13.9h.p. 1496cc Twelve Six, 12h/p/ 10cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.214 | 63.5 | 33.3375 | 14.2875 | 2.41 | 2 1/2 | 1 5/16 | 9/16 |
6 cyl piston set 7683 for Vauxhall - 12h.p. 1531cc DY, Twelve Six, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57 | 75.40625 | 39.6875 | 19.05 | 2.244094 | 2 31/32 | 1 9/16 | 3/4 |
4 cyl piston set 7695 for Hillman - 9.8h.p. 1185cc Minx, Minx Magnificent, Aero Minx
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 76.99375 | 38.89375 | 16 | 2.480315 | 3 1/32 | 1 17/32 | 0.629921 |
1 cyl piston set 7755 for Morris - 1931 14.9h.p. Major QX, 6 cyl, 1930 to 32 14.9h.p Oxford 6 cyl, 1933 to 34 Ten Four 4 cyl, 1934 - 1935 Fifteen Six
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 71.5 | 35 | 16 | 2 1/2 | 2.814961 | 1.377953 | 0.629921 |
6 cyl piston set 7787 for Austin - 16h.p. Export
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 76.2 | 38.1 | 15.875 | 2.57874 | 3 8.8817841970013E-16/2 | 1 1/2 | 5/8 |
4 cyl piston set 7795 for Austin - 10h.p. 1125cc Ten Four, 6/10cwt, Triton Marine Engine, Model A, B
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.85 | 31.75 | 14.2875 | 2 1/2 | 2 3/4 | 1 1/4 | 9/16 |
4 cyl piston set 7807 for Standard - 10h.p. 1343cc C.R. 5.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 77.390625 | 39.290625 | 15.875 | 2 1/2 | 3 3/64 | 1 35/64 | 5/8 |
4 cyl piston set 7815 for Standard - 10h.p. 1343cc Ten
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 78.184375 | 39.290625 | 19.05 | 2 1/2 | 3 5/64 | 1 35/64 | 3/4 |
4 cyl piston set 7984 for Standard - 10h.p. 1267cc Flying Ten C.R. 6.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 73.025 | 38.1 | 19.05 | 2 1/2 | 2 7/8 | 1 1/2 | 3/4 |
4 cyl piston set 8041 for Triumph - 11.8h.p. 1496cc, 1.5 litre Dolomite
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69 | 85 | 45 | 19.05 | 2.716535 | 3.346457 | 1.771654 | 3/4 |
4 cyl piston set 8112 for Standard - 8h.p. 1021cc, Flying Eight C.R 6.7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57 | 73.025 | 38.1 | 15.875 | 2.244094 | 2 7/8 | 1 1/2 | 5/8 |
6 cyl piston set 8238 for Austin - 26.88h.p. 3459cc CX13 1 1/2 to 5 ton 20-26 seater passenger bus C.R 5.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.09 | 93.6625 | 47.625 | 22.225 | 3.35 | 3 11/16 | 1 7/8 | 7/8 |
6 cyl piston set 8499 for Armstrong Siddeley - 14h.p. 1668cc
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 60.96 | 76 | 41 | 15.875 | 2.4 | 2.992126 | 1.614173 | 5/8 |
6 cyl piston set 8674 for Lanchester - 13.4h.p. 1527 cc Roadrider, Fourteen, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 59.944 | 69.85 | 31.75 | 15.24 | 2.36 | 2 3/4 | 1 1/4 | 0.6 |
6 cyl piston set 8735 for Lanchester - 14.06h.p. 1809 cc Fourteen, Roadrider De Luxe, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.468 | 80.16875 | 44.45 | 17.77 | 2.42 | 3 5/32 | 1 3/4 | 0.699606 |
4 cyl piston set 8754 for Packard - 1937 British Model 115. 1935-1947 33.8h.p. 4620 cc 120, 120B, 120C, 120CD, 138CD, 1601, 1601A, 1601D, 1602, 1701, 1701A, 1702, 1801, 1801A, 1901, 1901A, 2001,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 98.425 | 53.975 | 22.225 | 3 1/4 | 3 7/8 | 2 1/8 | 7/8 |
4 cyl piston set 8825 for Ford - V8 30h.p. 3622cc SV 3.6 litre Pilot, C.R 6.15 to 1 British Built Engine
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7875 | 81.75625 | 45.24375 | 19.05 | 3 1/16 | 3 7/32 | 1 25/32 | 3/4 |
1 cyl piston set 8909 for Daimler - 16.2h.p. 2166cc '15' DB17.1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.04 | 72 | 40 | 17.78 | 2.6 | 2.834646 | 1.574803 | 0.7 |
4 cyl piston set 8999 for Ford - 24h.p. A, AA, B, BB C.R. 4.6 to 1. Aluminium version of cast iron piston 8618
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 98.425 | 97.63125 | 48.41875 | 25.4 | 3 7/8 | 3 27/32 | 1 29/32 | 1 |
4 cyl piston set 9035 for Ford - 30h.p. Export V8, 18, 40, 48, 68, C.R 6.12 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7875 | 75.40625 | 38.89375 | 19.05 | 3 1/16 | 2 31/32 | 1 17/32 | 3/4 |
4 cyl piston set 9277 for Rover - 10h.p. 1185 cc Family 10
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 68.2625 | 33.3375 | 14.2875 | 2.480315 | 2 11/16 | 1 5/16 | 9/16 |
1 cyl piston set 9310 for Austin - 28.3h.p. 6 wheeler 4-wheel drive, twin rear axle K3/YF, 4-wheel drive K3/ZD, K5. Aluminium piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 93.6625 | 47.625 | 22.225 | 3 7/16 | 3 11/16 | 1 7/8 | 7/8 |
6 cyl piston set 9745 for Dodge - 27.3h.p. Aluminium version of cast iron piston 5297
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 97.63125 | 50.8 | 21.828125 | 3 3/8 | 3 27/32 | 2 | 55/64 |
4 cyl piston set 9984 for Singer - 9.93h.p. 1193cc Super 10, CR 7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.246 | 68 | 33 | 14.2875 | 2.49 | 2.677165 | 1.299213 | 9/16 |
1 cyl piston set 10154 for Bamford - EV3, EV4, EV5
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 107.95 | 90.884375 | 46.434375 | 25.4 | 4 1/4 | 3 37/64 | 1 53/64 | 1 |
2 cyl piston set 10261 for Petter - 1 Cyl A1, 2 Cyl A2
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.5 | 82.86 | 40 | 19 | 3.444882 | 3.262205 | 1.574803 | 0.748031 |
4 cyl piston set 10491 for Vauxhall - 1939/48 12h.p. 1442 cc Twelve Four, I, CR 6.8 to 1. 1948/52 1 1/2 litre, Wyvern LIX, CR 6.4 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 90.884375 | 55.165625 | 15.875 | 2.73622 | 3 37/64 | 2 11/64 | 5/8 |
1 cyl piston set 10567 for Commer - 26.85h.p. 4086cc SV, LNF5, N5, PN4, PNF4, PNF5, CPNF5, Q2, Q3, Q4, Q5, 2-6 1/2 ton, 24 to 26 seater passenger, Commando, Tractor Trailer 6-10ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85 | 93 | 51 | 24 | 3.346457 | 3.661417 | 2.007874 | 0.944882 |
6 cyl piston set 11147 for Morris - 28.16h.p. 4459 cc OHV 4 1/2 Litre, CDD3 Saurer Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87 | 126.20625 | 67.8688 | 34.925 | 3.425197 | 4 31/32 | 2.672 | 1 3/8 |
1 cyl piston set 11433 for International - Farmall M, MV, I6, IU6, O6, OS6, T6, W6, Power Unit U6, High Comp for 9591
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 98.425 | 146.05 | 90.4875 | 33.3375 | 3 7/8 | 5 3/4 | 3 9/16 | 1 5/16 |
4 cyl piston set 11594 for Hillman - 1185 cc SV Minx, MkI, MkII, MkIII
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 73.81875 | 38.89375 | 16 | 2.480315 | 2 29/32 | 1 17/32 | 0.629921 |
6 cyl piston set 11848 for Fordson - 3610 cc OHV Major Tractor, Vaporising Oil, CR 4.35 to 1, 24.8h.p. OHV Cost Cutter, 1 1/2 - 4 Ton, Petrol
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 99.9998 | 117.9576 | 71.0438 | 31.75 | 3.937 | 4.644 | 2.797 | 1 1/4 |
4 cyl piston set 12377 for Jaguar - 1609 cc 1.5 Litre
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 82 | 45.5 | 19.05 | 2.73622 | 3.228346 | 1.791339 | 3/4 |
4 cyl piston set 12455 for Hudson, Nash - 1932-39, 3475 cc Big 6, Custom 6, Terra Plane 6. 4168 cc Great 8, Pacemaker 8, Special 8, Deluxe 8, Custom 8. Late 1939-56, 3310 cc SV Super 6, Commodore...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 80.9625 | 42.8625 | 19.05 | 3 8.8817841970013E-16/2 | 3 3/16 | 1 11/16 | 3/4 |
4 cyl piston set 12574 for Austin - 15.99h.p. 2199cc OHV Sixteen from engine 1401 A70, Hampshire, Hereford, C.R 6.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.375 | 98.425 | 47.625 | 22.225 | 3 1/8 | 3 7/8 | 1 7/8 | 7/8 |
4 cyl piston set 12650 for Standard, Triumph - 948 cc OHV Ten, Pennant, 6 cwt Van, Atlas 10/12 Cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 66.1 | 38.1 | 15.875 | 2.480315 | 2.602362 | 1 1/2 | 5/8 |
4 cyl piston set 12866 for Austin - 10.65h.p. 1200 cc O.H.V. A40 Cambridge CR 7.2 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.4685 | 76.99375 | 42.1132 | 17.4625 | 2.5775 | 3 1/32 | 1.658 | 11/16 |
4 cyl piston set 13251 for Ford (American) - 1941-2 4Cyl 1NC/2NC/1ND/2ND/1NY/2NY, 1/2 - 1 Ton. 1939-47 32.5HP (95/100h.p. V8), (09/19/29/59/69/79/99)C, (09/29/69/79/99)D,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9625 | 80.9625 | 45.24375 | 19.05 | 3 3/16 | 3 3/16 | 1 25/32 | 3/4 |
4 cyl piston set 13807 for Hillman - 1390 cc OHV Minx, Mark VIII, Husky Series I and II, Low Comp CR 7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 82.55 | 46.99 | 22.225 | 3 8.8817841970013E-16/2 | 3 1/4 | 1.85 | 7/8 |
4 cyl piston set 14136 for MG - 1250 cc OHV Midget, 1 1/4 Litre, Series TB, TC, TD, TF, Y, YA, YB
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.5 | 73 | 45 | 18 | 2.61811 | 2.874016 | 1.771654 | 0.708661 |
1 cyl piston set 14816 for Austin - 2912 cc OHV A99 Westminster/A110 2.9 litre/ 3 litre Princess. CR 8.3 to 1 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83.3247 | 87.3125 | 47.625 | 22.225 | 3.2805 | 3 7/16 | 1 7/8 | 7/8 |
1 cyl piston set 15181 for Vauxhall - 2651 cc OHV 2.6 litre, Velox, Cresta
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 77.978 | 44.45 | 22.0091 | 3 1/4 | 3.07 | 1 3/4 | 0.8665 |
4 cyl piston set 16110 for Fiat - 1295 cc OHV 1300 CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 72 | 88.5 | 45.602 | 22 | 2.834646 | 3.484252 | 1.795354 | 0.866142 |
4 cyl piston set 16220 for Singer - 1494 cc OHV Gazelle, CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78.999 | 82.55 | 46.99 | 22.225 | 3.110197 | 3 1/4 | 1.85 | 7/8 |
1 cyl piston set 16639 for Vauxhall - 3293 cc OHV Velox, Cresta, Viscount, CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 92.075 | 77.9272 | 44.45 | 21.9964 | 3 5/8 | 3.068 | 1 3/4 | 0.866 |
6 cyl piston set 17308 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
Hillman Imp 875cc
Low comp 8.7:1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 70.2564 | 51.990625 | 26.590625 | 15.875 | 2.766 | 2 3/64 | 1 3/64 | 5/8 |
1 cyl piston set 17568 for Vauxhall - 1599 cc OHC Victor 1600, Viva 1600 SL, Firenza 1600 De Luxe SL, CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.7 | 83.312 | 45.3136 | 25.4 | 3.374016 | 3.28 | 1.784 | 1 |
4 cyl piston set 18111 for Hillman - 875 cc OHC Imp, Super Imp, Husky C.R 10 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 67.98564 | 52.1843 | 26.797 | 15.875 | 2.6766 | 2.0545 | 1.055 | 5/8 |
4 cyl piston set 18512 for Austin, Mini, Morris - OHV Mini Cooper Overbored to give 1095 cc, CR 10.25 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 51.384 | 31.547 | 15.875 | 2.57874 | 2.022992 | 1.242008 | 5/8 |
4 cyl piston set 18647 for Ford - Uprated 711M Engine, Ford Crossflow OHV Kent
1299 cc Original Application:
Ford Capri Mk1 1.3 08/1970-1974
Ford Capri Mk2/Mk3 1.3 1974-1987
Ford Cortina Mk3 1.3...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18685 for Ford - 1599 cc OHV Cortina 1600, Capri 1600, 2737E Engine, Low Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
1 cyl piston set 18943 for Ford - 997 cc OHV Anglia 105E Engine, CR 8.9 to 1. 1198 cc OHV Anglia Super, Cortina 113E Engine, CR 8.7 to 1. 1499 cc OHV Cortina Super, 116E Engine, CR 8.3 to 1. 1499...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9498 | 64.262 | 38.9636 | 20.6375 | 3.187 | 2.53 | 1.534 | 13/16 |
6 cyl piston set 19160 for Leyland - 2227 cc OHC 2200 E series/2200HL, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 74.7776 | 43.1292 | 20.6375 | 3 8.8817841970013E-16/2 | 2.944 | 1.698 | 13/16 |
1 cyl piston set 19298 for Ford - 7 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2994...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
4 cyl piston set 19470 for Hillman - 1295 cc OHV Avenger 1300, GL, GT, CR 8.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78.6 | 75.7682 | 44.1198 | 23.8125 | 3.094488 | 2.983 | 1.737 | 15/16 |
4 cyl piston set 19690 for Nissan - 1171 cc A12 Engine. Cherry 120a, Sunny 1200 120Y, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73 | 67.5 | 32.6 | 17.45 | 2.874016 | 2.65748 | 1.283465 | 0.687008 |
1 cyl piston set 19753 for Leyland - 1798 cc OHV 240, 250, Sherpa, CR 6.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.2513 | 61.1124 | 42.164 | 20.6375 | 3.1595 | 2.406 | 1.66 | 13/16 |
4 cyl piston set 19985 for Triumph - 1998 cc OHC TR7, CR 9.25 to 1. European Version
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.28684 | 70 | 34.1 | 23.8125 | 3.5546 | 2.755906 | 1.34252 | 15/16 |
4 cyl piston set 20183 for Mazda - 1586 cc NA Engine, OHC, Savanna, Capella, 616, 808, 818, B1600 Pick Up, CR 8.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78 | 78.15 | 41.25 | 22 | 3.070866 | 3.076772 | 1.624016 | 0.866142 |
4 cyl piston set 20264 for Land Rover - 3528 cc Rover V8, Range Rover SD1 Engine, CR 9.35 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.8619 | 77.089 | 47.371 | 22.225 | 3.4985 | 3.035 | 1.865 | 7/8 |
1 cyl piston set 20378 for Suzuki - 123 cc 1 Cyl TS125T, K, L, M, A, B, Two Stroke
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56 | 66.5 | 33.1 | 14 | 2.204724 | 2.61811 | 1.30315 | 0.551181 |
4 cyl piston set 20553 for Ford - 1599 cc OHV Transit 75/90/115, 751M Engine, Low Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 20950 for Austin, Mini, Morris - 998 cc A Series Mini Cooper, CR 8.4/9.1 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 60.72124 | 33.8582 | 15.875 | 2.542 | 2.3906 | 1.333 | 5/8 |
4 cyl piston set 21145 for Honda - 498 cc XL500, S/SZ/Z/A
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 89 | 65.2 | 29.2 | 21 | 3.503937 | 2.566929 | 1.149606 | 0.826772 |
4 cyl piston set 21813 for Nissan - 1595 cc L16 Engine. 1967-73; Bluebird 1600. 73-80; (P510). 73-80; Bluebird 160B (610, L610, LJ810, V610, VLJ810). 80-84; Bluebird 1.6 GL (TJ910, TLJ910)....
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83 | 78 | 38.1 | 21 | 3.267717 | 3.070866 | 1 1/2 | 0.826772 |
6 cyl piston set 164505 for Leyland - 5.76 Litre, 0350 Mk II, Comet 90, Comet 100, Tiger Club, Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 100.62718 | 132.715 | 81.915 | 33.02 | 3.9617 | 5.225 | 3.225 | 1.3 |
1 cyl piston set 350026 for Petter - PAZI, Air Cooled, Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 92 | 55.042 | 27 | 3 8.8817841970013E-16/2 | 3.622047 | 2.167008 | 1.062992 |
1 cyl piston set 350120 for Ford - Dexta 2000 Tractor, 158 cubic inches, Diesel. CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 106.68 | 134.112 | 75.2983 | 38.1 | 4.2 | 5.28 | 2.9645 | 1 1/2 |
1 cyl piston set 350188 for David Brown - DB1410, DB1412, AD 4/55 Engines, Turbocharged, Diesel, CR 16 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 100.04552 | 105.5624 | 60.3758 | 31.75 | 3.9388 | 4.156 | 2.377 | 1 1/4 |
1 cyl piston set 350258 for Leyland - 11.1 Litre Leyland TL11 Engine Turbocharged, Direct Injection Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 127.01524 | 169.6212 | 101.092 | 2 | 5.0006 | 6.678 | 3.98 | 0.07874 |
1 cyl piston set 350277 for Leyland - 4 Cyl, 3.77 Litre Leyland 4/98 Series, 6 cyl, 5.65 Litre, 6/98 Series, Turbocharged Diesel, Al Fin Design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 98 | 116.307 | 68.25 | 36.5125 | 3.858268 | 4.579016 | 2.687008 | 1 7/16 |
1 cyl piston set 350364 for Ford - 4/6 cyl 4149/6224cc Dover 90/130 Engine, 255/380 cubic inch Cargo Ceries Trucks 0606/0709, 380cu.in Cargo Series Trucks 0713/0813/0913/1013, Truck/Tipper...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 107.188 | 119.888 | 71.247 | 36.5125 | 4.22 | 4.72 | 2.805 | 1 7/16 |
2 cyl piston set 350385 for Bedford - 8200 cc 500 phase 1 engine. Direct injection TM Series 7400000 -> Al fin design for 350262
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 115.8875 | 122.4788 | 75.82916 | 44.45 | 4 9/16 | 4.822 | 2.9854 | 1 3/4 |
1 cyl piston set 350494 for Volkswagen - 1588 cc, Caddy, all models, Golf, Industry Engine, Jetta, Passat (not 1982/6), Rabbit (USA), Santana, Transporter 245/247/251/253/255, CR 23 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.5 | 71.7 | 41.7 | 24 | 3.011811 | 2.822835 | 1.641732 | 0.944882 |
4 cyl piston set 403801 for Alfa Romeo - 1186 cc 301.00 Engine, Alfasud L, N, SM, Super 1.2, Arna 1.2. CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 74 | 39 | 21 | 3.149606 | 2.913386 | 1.535433 | 0.826772 |
1 cyl piston set 554505 for Bedford - 6 cyl 7634 cc Direct Injection Diesel ERT/ERV/EPR/EMT/EMV/HMX/KMX, KG/KH/KM and YRT Series Trucks. CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 115.824 | 122.4026 | 75.7936 | 38.1 | 4.56 | 4.819 | 2.984 | 1 1/2 |
1 cyl piston set 586006 for David Brown - 3 cyl 2395 cc 770, 4cyl 3195 cc 990, Direct Injection Diesel, CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 100.04552 | 111.9124 | 66.7258 | 31.75 | 3.9388 | 4.406 | 2.627 | 1 1/4 |
4 cyl piston set 665362 for Fiat - 843 cc OHV, 850 normal and super Super Engine 100G CR 8.5 to 1. Special normal Engine 100GB CR 9.3 to 1. 903 cc OHV Coupe Engine 100 GC, Spider Engine 100GS,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65 | 67.25 | 36.75 | 20 | 2.559055 | 2.647638 | 1.44685 | 0.787402 |
4 cyl piston set 665946 for Fiat - 1438 cc 124 Coupe 2nd Series, 124 Sport, 125 2nd Series
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 81.45 | 41.95 | 22 | 3.149606 | 3.206693 | 1.651575 | 0.866142 |
6 cyl piston set 666973 for Fiat - 652 cc 126A, 126BB Engine, 2 Cyl, Air cooled. CR 7.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77 | 3.031496 | 0 | 0 | 0 | |||
4 cyl piston set 667509 for Alfa Romeo, Nissan - 1186 cc 301.00 Engine, Alfa Romeo Arna 1.2SI, Nissan Cherry 1.2, CR 9.1 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 74 | 39 | 21 | 3.149606 | 2.913386 | 1.535433 | 0.826772 |
4 cyl piston set 768110 for Simca - 1118 cc 1100, 1100L, 1100S, 350 Engine, CR 8.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74 | 67 | 40 | 22 | 2.913386 | 2.637795 | 1.574803 | 0.866142 |
4 cyl piston set 032.12.08 for Peugeot - 1124 cc XW7 Engine, OHC 104Z/ZR/ZA/GL/GR, 205 GL/GR/XL/XR. CR 9.7/10.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 72 | 73.5 | 40.05 | 19.5 | 2.834646 | 2.893701 | 1.576772 | 0.767717 |
4 cyl piston set 12587 JP for Austin - 8.3h.p. 803cc O.H.V. A30/Seven, CR 7.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57.912 | 65.0875 | 33.3375 | 14.2875 | 2.28 | 2 9/16 | 1 5/16 | 9/16 |
4 cyl piston set 18645 JP for Ford - 1098 cc OHV Escort 1100, Export Cortina 1100, 6/8 cwt Van. CR 9 to 1 Uprated 711M Engine
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
