Mini 850
5 ring - dish top - pinch bolt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62.9158 | 69.0118 | 38.0492 | 15.875 | 2.477 | 2.717 | 1.498 | 5/8 |
Bedford / Vauxhall
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.375 | 79.0448 | 45.593 | 19.05 | 3 1/8 | 3.112 | 1.795 | 3/4 |
6 cyl piston set 1965 for Chevrolet - 26h.p. LQ, LR, LT, BB, NA, NB, NC, ND, CU, 1/2, 1 1/2 Ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.1375 | 93.6625 | 47.625 | 25.146 | 3 5/16 | 3 11/16 | 1 7/8 | 0.99 |
1 cyl piston set 4330 for Lister - 5 h.p. B Type (Petrol)
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 114.3 | 114.3 | 50.8 | 25.4 | 4 1/2 | 4 1/2 | 2 | 1 |
1 cyl piston set 5246 for Morris - 24.8h.p. 3519cc SV, C, CD, CV Series 1 1/2 - 5 ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 100 | 107.95 | 57.15 | 26.9875 | 3.937008 | 4 1/4 | 2 1/4 | 1 1/16 |
4 cyl piston set 7168 for Standard - 10h.p. in 12h.p. chassis, 4 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 78.75 | 45.5 | 19.05 | 2 1/2 | 3.100394 | 1.791339 | 3/4 |
4 cyl piston set 7591 for Vulcan - 25.8h.p. Duchess 5VF, 6VF1/2/3 Tipper 5-6 ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 102 | 111.125 | 60.325 | 25.4 | 4.015748 | 4 3/8 | 2 3/8 | 1 |
4 cyl piston set 7684 for Ford - 30h.p. V8 Flat Top 15, 40, 60, 80cwt, Passenger 20 seater, Sussex and Surrey, Rigid Six, B, BB, 46, 50, 51, 67, 1/2 to 1 1/2 ton C.R. 6.12 to 1. Aluminium.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7875 | 75.40625 | 38.89375 | 19.05 | 3 1/16 | 2 31/32 | 1 17/32 | 3/4 |
1 cyl piston set 7763 for Morris - 11.9h.p. 1550cc SV Twelve Four S11 1937 to 37, 11.9h.p. OHV Twelve Four, 'T' Series III 1938 to 41
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 80.5 | 42.5 | 18 | 2.73622 | 3.169291 | 1.673228 | 0.708661 |
4 cyl piston set 7798 for Ford - 22h.p. V8 (Export 60h.p.) 73, 82C, 922C, )22C, 92D, 02D, 82Y, 92Y, 02Y, 75, Thames 1/2 to 6 ton C.R 6.6 to 1. Aluminium verson of piston 9036
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.04 | 71.040625 | 36.115625 | 17.4625 | 2.6 | 2 51/64 | 1 27/64 | 11/16 |
4 cyl piston set 7816 for Standard - 9h.p. 1131cc Flying Nine C.R.6.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 60 | 73.025 | 38.1 | 15.875 | 2.362205 | 2 7/8 | 1 1/2 | 5/8 |
4 cyl piston set 8089 for Ford - V8 3.6litre, Pilot V8 {Export 85h.p.) 78, 81A, 91A, 01A, 11A
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7875 | 81.75625 | 45.24375 | 19.05 | 3 1/16 | 3 7/32 | 1 25/32 | 3/4 |
6 cyl piston set 8243 for Vauxhall - 14.6h.p. 1781cc fourteen Six from Engine No. DX 520001, Drilled con-rod type
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.5 | 75.40625 | 39.6875 | 19.05 | 2.42126 | 2 31/32 | 1 9/16 | 3/4 |
4 cyl piston set 8674 for Lanchester - 13.4h.p. 1527 cc Roadrider, Fourteen, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 59.944 | 69.85 | 31.75 | 15.24 | 2.36 | 2 3/4 | 1 1/4 | 0.6 |
6 cyl piston set 8765 for Standard - 16h.p. 16/6 2143 cc Sixteen Flying Sixteen
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 77.390625 | 39.290625 | 19.05 | 2.57874 | 3 3/64 | 1 35/64 | 3/4 |
4 cyl piston set 8915 for Commer - 20.9h.p. 15, 20 25cwt, B20, NI
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 92.25 | 51 | 22 | 2.952756 | 3.63189 | 2.007874 | 0.866142 |
6 cyl piston set 9068 for Chevrolet - 100h.p. 235 motor
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.4875 | 101.6 | 52.3875 | 21.971 | 3 9/16 | 4 | 2 1/16 | 0.865 |
6 cyl piston set 9493 for Essex - 16.9h.p. Terraplane
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 67.46875 | 80.9625 | 42.8625 | 19.05 | 2 21/32 | 3 3/16 | 1 11/16 | 3/4 |
6 cyl piston set 10014 for Humber - 17.97h.p. 2731cc Snipe, Eighteen, CR 6.4 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 92.67 | 51 | 22 | 2.73622 | 3.648425 | 2.007874 | 0.866142 |
4 cyl piston set 10268 for Mercury - 100h.p. V8, 2-3 Ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9625 | 81.75625 | 45.24375 | 19.05 | 3 3/16 | 3 7/32 | 1 25/32 | 3/4 |
1 cyl piston set 10715 for Leyland - 3400 cc OHV 344 Tractor, CR 17.5 to 1, 4 cyl. 5103 cc OHV, 5.1 Litre, Redline Laird, Redline Terrier, CR 16.5 to 1, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 95 | 120.8024 | 70.2564 | 34.925 | 3.740157 | 4.756 | 2.766 | 1 3/8 |
4 cyl piston set 11542 for Continental - N62 (For Gasoline to 5000ft, Kerosene/Distillate above)
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 60.325 | 57.15 | 31.75 | 13.7922 | 2 3/8 | 2 1/4 | 1 1/4 | 0.543 |
1 cyl piston set 11920 for Ford - 10h.p. 1172 cc SV Taunas 12M, Anglia, Prefect, Escort, Squire, 1600 Series
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 74.678 | 45.34 | 17.4625 | 2 1/2 | 2.940079 | 1.785039 | 11/16 |
4 cyl piston set 12541 for Austin - 10.6h.p. 1200 cc O.H.V. A40 Sports/A40 Somerset. CR 7.2 to 1. (RBP)
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.4812 | 75.184 | 40.259 | 15.875 | 2.578 | 2.96 | 1.585 | 5/8 |
4 cyl piston set 12682 for Hillman - 1390 cc OHV Minx, Mark VIII, Husky Series I and II, CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 82.55 | 46.99 | 22.225 | 3 8.8817841970013E-16/2 | 3 1/4 | 1.85 | 7/8 |
4 cyl piston set 12866 for Austin - 10.65h.p. 1200 cc O.H.V. A40 Cambridge CR 7.2 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.4685 | 76.99375 | 42.1132 | 17.4625 | 2.5775 | 3 1/32 | 1.658 | 11/16 |
6 cyl piston set 13517 for Rover - 19.8h.p. 2638 cc 90, 2.6 Litre, CR 6.73 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.025 | 94.488 | 62.738 | 17.4625 | 2 7/8 | 3.72 | 2.47 | 11/16 |
4 cyl piston set 13598 for Austin - 1489 cc OHV A50 Cambridge, High Comp CR 8.2 to 1. A50/A55 CR 8.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.025 | 76.99375 | 42.06875 | 17.4625 | 2 7/8 | 3 1/32 | 1 21/32 | 11/16 |
4 cyl piston set 14332 for Dodge - D55-1 Coronet, D55-2 Royal, D55-3 Royal Lancer, Custom Royal, D63-1 Coronet, D55-3 Royal Lancer, Custom Royal, D61-1 Crusader, D61-2 Regent, D61-3 Mayfair, from...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 92.075 | 81.75625 | 42.8625 | 21.8186 | 3 5/8 | 3 7/32 | 1 11/16 | 0.859 |
6 cyl piston set 14635 for Mercedes - 3794 cc OHV Majestic, 3.8 litre, CR 7.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86.35238 | 87.709375 | 47.0408 | 22.225 | 3.3997 | 3 29/64 | 1.852 | 7/8 |
4 cyl piston set 15635 for Volkswagen - 1192 cc OHV 15 cwt. Van, Kombi, Multibus, RWD, Air Cooled CR 7 to 1, 1200 RWD Air Cooled 113 Motor, CR 7 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77 | 79 | 39 | 20 | 3.031496 | 3.110236 | 1.535433 | 0.787402 |
4 cyl piston set 16204 for Austin - 1098 cc OHV A40 MkII, 1100 Low Comp CR 7.5 to 1/ A35 6 Cwt Van, 7.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 58.1152 | 30.3276 | 15.875 | 2.542 | 2.288 | 1.194 | 5/8 |
1 cyl piston set 16219 for Hillman - 1494 cc OHV Minx, 1 1/2 litre, CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78.99908 | 82.6008 | 47.0408 | 22.225 | 3.1102 | 3.252 | 1.852 | 7/8 |
4 cyl piston set 16412 for Rover - 1997 cc 60, 2 Litre, CR 6.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.8 | 93.2942 | 61.5442 | 3.062992 | 3.673 | 2.423 | ||
4 cyl piston set 16494 for Renault - 1963-66 1108 cc OHV R8, 1100, Major, Caravelle, 1133, CR 8.5 to 1. 1965-66 R8 1100 Gordini, R8 Automatoc, CR 10.4 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 70 | 68 | 40 | 18 | 2.755906 | 2.677165 | 1.574803 | 0.708661 |
4 cyl piston set 17215 for Vauxhall - 1159 cc OHV Viva De-Luxe, SL, CR 8.5 to 1 (Low Comp 7.3 to 1). 90 De Luxe, 90 SL, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7494 | 75.565 | 37.6174 | 20 | 3.061 | 2.975 | 1.481 | 0.787402 |
4 cyl piston set 17271 for Austin - 1275 cc OHV Healey Sprite, MkIV. CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 70.612 | 69.6849 | 38.0365 | 20.6375 | 2.78 | 2.7435 | 1.4975 | 13/16 |
4 cyl piston set 17357 for Austin, Morris - 1798cc OHV 1800 CR 8.2 to 1, RBP
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.2513 | 76.99375 | 42.06875 | 20.6375 | 3.1595 | 3 1/32 | 1 21/32 | 13/16 |
1 cyl piston set 17404 for Volkswagen - 1285 cc OHV 1300 RWD, Air Cooled. CR 7.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77 | 80 | 40 | 22 | 3.031496 | 3.149606 | 1.574803 | 0.866142 |
4 cyl piston set 17525 for Austin, MG, Wolsely - 1798cc OHV 1800 - CR 8.4 to 1/1800 MkII CR 9 to 1/1800s MkII CR 9.5 to 1, MGB. Circlip Type
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.2513 | 61.11875 | 42.06875 | 20.6375 | 3.1595 | 2 13/32 | 1 21/32 | 13/16 |
4 cyl piston set 17563 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Capri 1300, 8 Cwt Van, 2735E Engine, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
1 cyl piston set 17753 for Triumph - 2498 cc OHV TR5PI, TR6PI, 2.5PI, CR 9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74.6887 | 61.976 | 28.971875 | 20.6375 | 2.9405 | 2.44 | 1 9/64 | 13/16 |
4 cyl piston set 18005 for Austin - 1485 cc OHC Maxi 1500. 1.5 Litre. CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 74.8284 | 43.0784 | 20.6375 | 3 8.8817841970013E-16/2 | 2.946 | 1.696 | 13/16 |
4 cyl piston set 18400 for Ford - 997 cc OHV Anglia, Thames 5-7 Cwt, 105E Engine, Perfect 107E Engine, CR 8.9 to 1, Thames 5-7 Cwt 307E Engine CR 7.5 to 1. 1198 cc OHV Anglia Super, Cortina,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9498 | 77.216 | 38.9636 | 20.6375 | 3.187 | 3.04 | 1.534 | 13/16 |
4 cyl piston set 18496 for Hillman - 1498 cc OHV Avenger Grand Luxe, GT CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86.12124 | 75.803125 | 44.053125 | 23.8125 | 3.3906 | 2 63/64 | 1 47/64 | 15/16 |
4 cyl piston set 18598 for Vauxhall - 3294 cc OHV Velox, Cresta, Viscount, Ventora, Victor 3300, CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 92.075 | 77.978 | 44.5008 | 22.0091 | 3 5/8 | 3.07 | 1.752 | 0.8665 |
4 cyl piston set 18646 for Ford - 1098 cc OHV Escort 1100, 6/8 cwt Van. Low Comp CR 8 to 1. Uprated 711M Engine
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
1 cyl piston set 18682 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Capri 1300, 8 Cwt Van, 2735E Engine, Low Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18684 for Ford - 1599 cc OHV Cortina 1600, 1600GT, Capri 1600, 2737E Engine, CR 9 to 1. 1599 cc OHV Capri 1600GT CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18762 for Hillman - 1592 cc OHV Minx 1600, Super Minx Low Comp CR 7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 81.53908 | 82.55 | 46.99 | 23.8125 | 3.2102 | 3 1/4 | 1.85 | 15/16 |
4 cyl piston set 18924 for Vauxhall - 1256 cc OHV Viva De Luxe, Firenza De Luxe SL, CR 8.5 to 1. 1975 On, Chevette CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.95 | 70.1294 | 38.227 | 20 | 3.187008 | 2.761 | 1.505 | 0.787402 |
1 cyl piston set 19114 for Vauxhall - 1759 cc Bedford CF 1800 14-18 cwt Vans OHC. Vauxhall OHC Victor 1800 De luxe, Viva 1800 De Luxe SL, Firenza 1800 De Luxe SL, Magnum 1800, Low Comp, CR 7.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.6996 | 77.216 | 39.2176 | 25.4 | 3.374 | 3.04 | 1.544 | 1 |
4 cyl piston set 19132 for Ford - 2494 cc OHV Consul, Consul L, Granada, Granada GXL, 2.5 litre V6 CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 101.346 | 52.1716 | 23.8125 | 3.6869 | 3.99 | 2.054 | 15/16 |
4 cyl piston set 19275 for Austin - 1748 cc OHC Maxi 1750HL, CR 9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 63.6905 | 35.84194 | 20.6375 | 3 8.8817841970013E-16/2 | 2.5075 | 1.4111 | 13/16 |
2 cyl piston set 19298 for Ford - 6 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2994...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
1 cyl piston set 19300 for Ford - 1966 onwards 4 cyl 1996 cc OHV Corsair GT, Zephyr 4 MkIV, Corsair 2000, 2000E, Capri, 2000GT, 1972 onwards OHV Consul, Consul L, 2 litre V4 CR 10 to 1. 6 cyl 2994...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.996 | 46.1391 | 23.8125 | 3.6869 | 3.74 | 1.8165 | 15/16 |
4 cyl piston set 19377 for Audi - 1760 cc Audi Super 90, 1800-S90 CR 10.6 to 1, 1770 cc OHV Audi 100 LS/S, 1800S Engine, CR 10.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 81.5 | 72.5 | 43.5 | 24 | 3.208661 | 2.854331 | 1.712598 | 0.944882 |
4 cyl piston set 19569 for Volkswagen - 1285 cc 1302, 1303. CR 7.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77 | 82.8 | 42.8 | 22 | 3.031496 | 3.259843 | 1.685039 | 0.866142 |
4 cyl piston set 19659 for Nissan - 988 cc A10 Engine. 79-81; Cherry 1.0 L, GL. 70-76; Cherry 100A Deluxe L. 76-79; Chery F11, GLS. 66-70; Sunny 1000
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73 | 67.5 | 32.6 | 17.45 | 2.874016 | 2.65748 | 1.283465 | 0.687008 |
4 cyl piston set 19737 for Toyota - 1588 cc 2T, 2TB, 2TC, Engines, Carina, CR 8.5 to 1, Celica 1600 ST, CR 9.4 to 1. Corolla
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85 | 90.75 | 45.1 | 22 | 3.346457 | 3.572835 | 1.775591 | 0.866142 |
4 cyl piston set 19753 for Leyland - 1798 cc OHV 240, 250, Sherpa, CR 6.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.2513 | 61.1124 | 42.164 | 20.6375 | 3.1595 | 2.406 | 1.66 | 13/16 |
4 cyl piston set 19915 for Ford - 1599 cc OHV Transit 75/90/115, 751M Engine, Low Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 19975 for Land Rover - OHV Series II, IIA, III, 2 1/4 Litre, CR 7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.4748 | 99.9236 | 58.5216 | 25.4 | 3.562 | 3.934 | 2.304 | 1 |
1 cyl piston set 20128 for Land Rover - 2286 cc OHV Series II, IIA, III, 2 1/4 Litre, Rover 80, CR 7 to 1, Optional 4 Ring design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.4748 | 99.9236 | 58.5216 | 25.4 | 3.562 | 3.934 | 2.304 | 1 |
4 cyl piston set 20140 for Triumph - 1296 cc 1300, Herald 13/60, Toledo, Dolomite 1300, CR 8.5 to 1. 1300 TC, Spitfire (Engine RD19477 On), CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.6473 | 66.9671 | 38.4937 | 20.6375 | 2.8995 | 2.6365 | 1.5155 | 13/16 |
4 cyl piston set 20216 for Honda - 1600 cc EF Engine, OHC Accord, CR 8.4 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74 | 57.5 | 27.6 | 17 | 2.913386 | 2.26378 | 1.086614 | 0.669291 |
4 cyl piston set 20234 for Honda - 1238 cc EB2 Engine, Civic 1500, CVCC, CR 8.1 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 72 | 60 | 27.1 | 17 | 2.834646 | 2.362205 | 1.066929 | 0.669291 |
1 cyl piston set 20359 for Suzuki - 739 cc GT500, GT750, J, K, L, M, A, B Two Stroke 3 Cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 70 | 79.8 | 36.9 | 18 | 2.755906 | 3.141732 | 1.452756 | 0.708661 |
4 cyl piston set 20510 for Audi - 1272 cc Audi 50LS/GLS. CR 8.2 to 1, Pyrostrut design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75.01 | 65.55 | 38.65 | 20 | 2.95315 | 2.580709 | 1.521654 | 0.787402 |
4 cyl piston set 20551 for Ford - 1291 cc 751M Engine, OHV Cortina 1300, Escort 6-8 Cwt Van, Escort 1300, Popular 1300, Low Comp, CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
1 cyl piston set 20646 for Mercedes - 2778 cc M130, 920/921 Engine, 6 cyl, 250C, 280S/SE/SL, 300SEL, U110.404, CR 8.7/9/9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86.5 | 81.2 | 48 | 25 | 3.405512 | 3.19685 | 1.889764 | 0.984252 |
4 cyl piston set 20760 for Ford - 1597 cc CVH Engine OHC, Escort 1600L, GL, Ghia, Estate, XR3, CR 9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.99984 | 20.6375 | 3.1496 | 0 | 0 | 13/16 | ||
4 cyl piston set 21069 for Mitsubishi - 1410 cc G12B, 4G12 Engine, OHC Mirage 1400, GL/GLX/GLS, Lancer 1400 EL/GL/SL, Celeste 1400 SR/GL/GSL Coupe. CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.5 | 58 | 28.9 | 18 | 3.011811 | 2.283465 | 1.137795 | 0.708661 |
4 cyl piston set 21077 for Austin, Morris - 1993 cc Princess 2000HL/HLS, Morris OHC Ital 2000 HLS Saloon/Estate, Ambassador 2.0 HL/HLS, Montego 2.0 HL/HLS, 'O' Series Engine, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.4423 | 60.2488 | 35.30092 | 20.6375 | 3.3245 | 2.372 | 1.3898 | 13/16 |
1 cyl piston set 21250 for Austin, Morris - 1275 cc A+ series, Maestro 1.3/L/HL/HLE, Metro L/HL/HLE/HLS/S, Montego 1.3, CR 9.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 70.6247 | 57.98566 | 38.0492 | 20.6375 | 2.7805 | 2.2829 | 1.498 | 13/16 |
4 cyl piston set 21418 for Ford - 1593 cc EMAX Engine OHC Sierra 1600 E/LE/GLE/Ghia E, CR 9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 81.3 | 64.55 | 41.6 | 20.63242 | 3.200787 | 2.541339 | 1.637795 | 0.8123 |
4 cyl piston set 22009 for Ford - 1297 cc Escort 1300 Popular L, Combi Van, Orion 1300 L
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.96 | 65.1 | 38.69 | 20.62988 | 3.699213 | 2.562992 | 1.523228 | 0.8122 |
4 cyl piston set 23974 for Mercedes - 1997 cc M102E20 Engine 190E, 190E Catalyst, 200E, CE, E Catalyst, GE 4x4, TE CR 9.1 to 1. M102V20 Engine 190, 200, 200T, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 89 | 79.7 | 43.2 | 22 | 3.503937 | 3.137795 | 1.700787 | 0.866142 |
1 cyl piston set 249203 for Petter - PH Series, Diesel, CR 16.5 to 1. 3 7/16" bore for water cooled, 3.4435" for air cooled
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 106 | 63.5 | 30 | 3 7/16 | 4.173228 | 2 1/2 | 1.181102 |
1 cyl piston set 350047 for Petter - PJ Series, Diesel, CR 17.5 to 1. Air cooled 3.8175" bore, Water cooled is 3.814"
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 96.9645 | 106.0958 | 63.6016 | 30 | 3.8175 | 4.177 | 2.504 | 1.181102 |
1 cyl piston set 350079 for Ford - 360 cubic inches, D800, D900, D1000, DT1500, R Series. Turbocharged Diesel, CR 15.7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 104.775 | 119.888 | 71.2216 | 36.5125 | 4 1/8 | 4.72 | 2.804 | 1 7/16 |
1 cyl piston set 350208 for Mercedes, Daimler Benz - 1988 cc OM615.913/915/937 Engines, 200D, L206D, L306D. Diesel. CR 21 to 1, Steel Strut Design.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87 | 87.42 | 52.9 | 26 | 3.425197 | 3.441732 | 2.082677 | 1.023622 |
1 cyl piston set 350254 for Petter - PH1, 1W, 2, 2W, 1/2 Cyls, Air cooled bore is 3.4435", Water is 3.4375"
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 105.9942 | 63.6016 | 30 | 3 7/16 | 4.173 | 2.504 | 1.181102 |
4 cyl piston set 350305 for Bedford, Ford Europe - 1760 cc CF220/250 Van, Transit CR 22 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.375 | 80.01 | 50.63236 | 26.9875 | 3 1/8 | 3.15 | 1.9934 | 1 1/16 |
1 cyl piston set 350341 for Lister - HR, HRW Series, 2/3 Cyls, Diesel. Water cooled Diameter is 4 1/4, Air Cooled is 4.252
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 107.95 | 127 | 73.0758 | 39.6875 | 4 1/4 | 5 | 2.877 | 1 9/16 |
1 cyl piston set 350417 for Gardner - 15.5 litre 6LYT Automotive Engine 15500 cc Direct Injection Turbocharged Diesel, CR 15 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 140 | 200.25 | 122.3 | 58 | 5.511811 | 7.883858 | 4.814961 | 2.283465 |
1 cyl piston set 350490 for Volvo - 6725 cc, TD71E, TD71FD, TD71F, 71G, TD71FSO, TD71SQ Engines. Turbocharged Diesel CR 15 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 104.648 | 141.05 | 88.45 | 45 | 4.12 | 5.55315 | 3.482283 | 1.771654 |
4 cyl piston set 479404 for Perkins - 1621 cc OHV 4.99, 1.62 Litre Diesel after Engine No 7034968, CR 20 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 79.9211 | 45.7835 | 23.8125 | 3 8.8817841970013E-16/2 | 3.1465 | 1.8025 | 15/16 |
4 cyl piston set 544009 for Lister - LR Series, Air Cooled Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 103.1875 | 65.0875 | 25.4 | 3 8.8817841970013E-16/2 | 4 1/16 | 2 9/16 | 1 |
4 cyl piston set 663395 for Fiat - 633 cc OHV 600, Multipla RPB
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 60 | 70 | 40.8 | 18 | 2.362205 | 2.755906 | 1.606299 | 0.708661 |
4 cyl piston set 665017 for Fiat - 1221 cc OHV 1100D Europa, 1200 Gran Luxe Spider, Engine type 103 G CR 8.1 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 72 | 82 | 46 | 22 | 2.834646 | 3.228346 | 1.811024 | 0.866142 |
4 cyl piston set 666298 for Fiat - 1290 cc 128, 1300 Saloon, Estate, Rally Special, Sport Coupe/L, 3P, X1/9, CR 8.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86 | 77.3 | 35.35 | 22 | 3.385827 | 3.043307 | 1.391732 | 0.866142 |
4 cyl piston set 667061 for Fiat - 4 cyl, 1049 cc 127AB.OC.O and 127AB.ON.O Engines, OHC. 127-1050 CL, 127 Fiorino, 147 Brazil, 60L Ritmo, CR 9.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76 | 76.05 | 36.05 | 22 | 2.992126 | 2.994094 | 1.419291 | 0.866142 |
4 cyl piston set 667597 for Fiat - 1714 cc M700AA.17.0 Engine, 131 Mirafiori, 1600, 131, L, CL, Panorama, Regata Diesel, Ritmo Diesel, Strada/Ritmo Diesel. CR 20 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83 | 85 | 45.9 | 22 | 3.267717 | 3.346457 | 1.807087 | 0.866142 |
4 cyl piston set 768120 for Simca - 1118 cc 1100G, 1100GLS, 350 Engine. CR 9.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74 | 67 | 40 | 22 | 2.913386 | 2.637795 | 1.574803 | 0.866142 |
4 cyl piston set 036110 for Simca - 1290 cc OHV 1301S, 1301LS, 1301GL, CR 9 to 1, 1301GLS, CR 9.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74 | 90.3 | 52 | 22 | 2.913386 | 3.555118 | 2.047244 | 0.866142 |
4 cyl piston set 129.14.07 for Peugeot - 2304 cc XD2-XD2P-XD94 Engines, 504 GLD/Berline/Familiale, 505 GRD/SRD, J7 PX/PY/PZ, J9, CR 22.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 94 | 99.9 | 57.42 | 28 | 3.700787 | 3.933071 | 2.26063 | 1.102362 |
