| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
Land Rover 2 1/4 Diesel S2 and S3
3.562" Bore Size STD plus oversizes
same as 350001 pistons
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.4748 | 100.0252 | 58.5978 | 30.1625 | 3.562 | 3.938 | 2.307 | 1 3/16 |
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
4 cyl piston set 3889 for Morris - 19.2h.p. R, TX, 2 ton, Economy model
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88 | 44.45 | 95.25 | 22.225 | 3.464567 | 1 3/4 | 3 3/4 | 7/8 |
1 cyl piston set 5055 for Fiat - 17h.p. 2516cc 518, Ardita 2000, Type O
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82 | 102 | 48 | 24 | 3.228346 | 4.015748 | 1.889764 | 0.944882 |
4 cyl piston set 7058 for Albion - 22.5h.p. HL126, J127, JS127, JL127, KN126, KL126, KS127, KN127, KL127, 70/80/90/100/110cwt, PH, PK114, 115, 24/36 seater passenger, Victor, EN212, EN68A, EN215,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 95.25 | 98.425 | 44.45 | 28.575 | 3 3/4 | 3 7/8 | 1 3/4 | 1 1/8 |
4 cyl piston set 7557 for Commer - 13.95h.p. 15, 20, 25cwt NI Series A Q15, Q25
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 93 | 51 | 24 | 2.952756 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 7681 for Vauxhall - 10h.p. 1203cc Ten Four, H, C.R. 6.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 75.40625 | 39.6875 | 15.875 | 2 1/2 | 2 31/32 | 1 9/16 | 5/8 |
4 cyl piston set 7751 for Standard - 9h.p. 1287cc Teinmouth Big Nine, C.R. 4.9 to 1, 4 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 76.2 | 38.1 | 15.875 | 2 1/2 | 3 8.8817841970013E-16/2 | 1 1/2 | 5/8 |
4 cyl piston set 7789 for Ford - 10h.p. 10cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 64.29375 | 26.19375 | 17.4625 | 2 1/2 | 2 17/32 | 1 1/32 | 11/16 |
6 cyl piston set 7812 for Morris - 14h.p. 1818cc Series II & III Fouteen Six 'Q'
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.5 | 79.5 | 42.5 | 18 | 2.42126 | 3.129921 | 1.673228 | 0.708661 |
4 cyl piston set 8027 for Morris - 10h.p. 1140cc Series M, SM Ten Four
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 73.5 | 45 | 16 | 2 1/2 | 2.893701 | 1.771654 | 0.629921 |
6 cyl piston set 8237 for Austin - 16h.p. Engine fitted to 12-6 chassis 1934-38, 16h.p. 1711cc Fourteen, Goodwood 1937-40, C.R 6.4 to 1, Tornado Marine Engine Model. 6 Cylinder
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 72.23125 | 33.3375 | 14.2875 | 2.57874 | 2 27/32 | 1 5/16 | 9/16 |
6 cyl piston set 8674 for Lanchester - 13.4h.p. 1527 cc Roadrider, Fourteen, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 59.944 | 69.85 | 31.75 | 15.24 | 2.36 | 2 3/4 | 1 1/4 | 0.6 |
4 cyl piston set 8743 for Ford - 10h.p. 1172cc Prefect, long 4 ring piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.85 | 30.95625 | 17.4625 | 2 1/2 | 2 3/4 | 1 7/32 | 11/16 |
4 cyl piston set 8863 for Opel - 11.3h.p. 1.1 Cadet, 1.3 Olympia
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 67.5 | 2.65748 | 0 | 0 | 0 | |||
1 cyl piston set 9029 for Buick - 37.81h.p. M.O Type 60, 70, 80, 90 Series, Century, Roadmaster, Limited, 8 cylinder
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 113.50625 | 69.05625 | 22.225 | 3 7/16 | 4 15/32 | 2 23/32 | 7/8 |
6 cyl piston set 9309 for Austin - 26.88h.p. 3459cc CX13, 1 1/2 to 5 ton, 20-26 seater passenger bus C.R. 5.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.09 | 93.6625 | 47.625 | 22.225 | 3.35 | 3 11/16 | 1 7/8 | 7/8 |
1 cyl piston set 9859 for JAP - 8h.p. 55, 2 cyl, Air Cooled industrial Stationary
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 76.8858 | 38.7858 | 20.6375 | 3.149606 | 3.027 | 1.527 | 13/16 |
6 cyl piston set 10170 for Bedford - 27.34h.p. 3519cc, series K, M, O, W, 3/4 to 5 Ton, Tractor 6 to 8 Ton, Cast Iron Piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 85.725 | 41.275 | 20.6375 | 3 3/8 | 3 3/8 | 1 5/8 | 13/16 |
6 cyl piston set 10567 for Commer - 26.85h.p. 4086cc SV, LNF5, N5, PN4, PNF4, PNF5, CPNF5, Q2, Q3, Q4, Q5, 2-6 1/2 ton, 24 to 26 seater passenger, Commando, Tractor Trailer 6-10ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85 | 93 | 51 | 24 | 3.346457 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 11309 for Standard - 4 Cyl, 1776 cc Flying Fourteen. 6 Cyl 2664 cc Flying Twenty
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.025 | 82.2 | 45.7 | 19.05 | 2 7/8 | 3.23622 | 1.799213 | 3/4 |
4 cyl piston set 11594 for Hillman - 1185 cc SV Minx, MkI, MkII, MkIII
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 73.81875 | 38.89375 | 16 | 2.480315 | 2 29/32 | 1 17/32 | 0.629921 |
6 cyl piston set 11809 for Humber - 29.4 h.p. 4139 cc OHV Super Snipe, Mk IV, Pullman, Imperial
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9 | 112.9538 | 66.675 | 28.575 | 3 1/2 | 4.447 | 2 5/8 | 1 1/8 |
4 cyl piston set 12332 for Standard, Triumph - 2088 cc OHV 2.1 litre, 20S, Vanguard Four, Triumph 2.1 litre Roadster, 1800, 2000, Renown.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85 | 87.4268 | 50.9016 | 22.225 | 3.346457 | 3.442 | 2.004 | 7/8 |
4 cyl piston set 12417 for Austin - 8h.p. 900 cc Big Seven/New Eight, C.R. 6.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56.769 | 63.5 | 31.75 | 12.7 | 2.235 | 2 1/2 | 1 1/4 | 1/2 |
4 cyl piston set 12572 for Austin - 18.9h.p. 2660 cc O.H.V. Atlantic A90/Healey Hundred, 2.7 Lit. CR 7.5 to 1-4 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 90.4875 | 50.8 | 22.225 | 3 7/16 | 3 9/16 | 2 | 7/8 |
4 cyl piston set 12629 for Morris - 1955-6 1489 cc OHV A50 Cambridge. 1957-61, A50, A55. 1956-62 152 series, Omnivan, Omnitruck, 15 Cwt. Omnicoach, 10 Cwt. Van, J4 10/15 Cwt. Low Comp CR 7.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.025 | 76.99375 | 42.06875 | 17.4625 | 2 7/8 | 3 1/32 | 1 21/32 | 11/16 |
4 cyl piston set 12866 for Austin - 10.65h.p. 1200 cc O.H.V. A40 Cambridge CR 7.2 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.4685 | 76.99375 | 42.1132 | 17.4625 | 2.5775 | 3 1/32 | 1.658 | 11/16 |
2 cyl piston set 13155 for Rotary Hoe - 810 cc Gem Series IV, Air Cooled RBP
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 73.81875 | 40.48125 | 19.05 | 3 8.8817841970013E-16/2 | 2 29/32 | 1 19/32 | 3/4 |
4 cyl piston set 13598 for Austin - 1489 cc OHV A50 Cambridge, High Comp CR 8.2 to 1. A50/A55 CR 8.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.025 | 76.99375 | 42.06875 | 17.4625 | 2 7/8 | 3 1/32 | 1 21/32 | 11/16 |
4 cyl piston set 14054 for Hillman - 1494 cc OHV, Minx 1 1/2 Litre CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79 | 82.55 | 46.99 | 22.225 | 3.110236 | 3 1/4 | 1.85 | 7/8 |
4 cyl piston set 14814 for Austin - 2912cc OHV Healey 3000 2.9 Litre. CR 9.03 to 1. 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83.3247 | 87.3125 | 47.625 | 22.225 | 3.2805 | 3 7/16 | 1 7/8 | 7/8 |
6 cyl piston set 15001 for Fiat - 2054 cc OHV 2100, 2.1 Litre CR 8.8 to 1, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77 | 85.5 | 48.5 | 22 | 3.031496 | 3.366142 | 1.909449 | 0.866142 |
4 cyl piston set 15642 for Triumph - 1147 cc OHV Herald 1200, Herald 12/50, Spitfire, Courier 5 cwt. CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.28866 | 74.3458 | 38.4556 | 20.6375 | 2.7279 | 2.927 | 1.514 | 13/16 |
4 cyl piston set 16195 for Simca - 944 cc OHV 1000, RWD
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 68 | 68 | 35.5 | 19 | 2.677165 | 2.677165 | 1.397638 | 0.748031 |
4 cyl piston set 16205 for Ford - 997 cc OHV Anglia, Thames 5-7 Cwt, 105E Engine, Perfect 107E Engine, CR 8.9 to 1, Thames 5-7 Cwt 307E Engine CR 7.5 to 1. 1198 cc OHV Anglia Super, Cortina,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9498 | 77.1398 | 38.89375 | 20.6375 | 3.187 | 3.037 | 1 17/32 | 13/16 |
4 cyl piston set 16309 for Wolseley - 998 cc OHV Hornet, CR 8.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 65.8368 | 34.0868 | 15.875 | 2.542 | 2.592 | 1.342 | 5/8 |
4 cyl piston set 16412 JP for Rover - 1998 cc 60, 2 Litre, CR 6.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.8 | 93.2942 | 61.5442 | 3.062992 | 3.673 | 2.423 | ||
2 cyl piston set 16993 for Honda - 125 cc OHC Benly C92, CR 8.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 44 | 53 | 30 | 14 | 1.732283 | 2.086614 | 1.181102 | 0.551181 |
4 cyl piston set 17215 for Vauxhall - 1159 cc OHV Viva De-Luxe, SL, CR 8.5 to 1 (Low Comp 7.3 to 1). 90 De Luxe, 90 SL, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7494 | 75.565 | 37.6174 | 20 | 3.061 | 2.975 | 1.481 | 0.787402 |
1 cyl piston set 17308 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
4 cyl piston set 17358 for MG - 1798 cc OHV MGB1800, MGBGT, CR 8.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.2513 | 76.99375 | 42.06875 | 20.6375 | 3.1595 | 3 1/32 | 1 21/32 | 13/16 |
4 cyl piston set 17490 for Opel - 4 cyl 1492 cc OHC Rekord, Caravan, 1.5 Litre. 6 Cyl 2239 cc OHC Rekord L, Commodore, Coupe, 2200. CR 8.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.5 | 87 | 45 | 23 | 3.248031 | 3.425197 | 1.771654 | 0.905512 |
4 cyl piston set 17547 for Toyota - 1587 cc 4R Engine, OHV Corona 1600 S, CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.5 | 82.75 | 43.75 | 20 | 3.169291 | 3.257874 | 1.722441 | 0.787402 |
4 cyl piston set 17569 for Vauxhall - 1599 cc OHC Victor 1600, Viva 1600 SL, Firenza 1600 De Luxe SL, Low Comp, CR 7.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.7 | 81.8388 | 43.8404 | 25.4 | 3.374016 | 3.222 | 1.726 | 1 |
4 cyl piston set 17840 for Saab, Triumph - 1709 cc OHC, CR 8.8 to 1 to Engine JBB7509
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 64.5668 | 34.0868 | 20.6375 | 2.542 | 2.542 | 1.342 | 13/16 |
1 cyl piston set 18246 for BSA - 150 cc F15 industrial - RBP
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.9859 | 57.5564 | 35.8902 | 14.2875 | 2.5585 | 2.266 | 1.413 | 9/16 |
1 cyl piston set 18444 for Hillman - 1592 cc OHV Minx 1600, Super Minx High Comp. CR 8.83 to 1. 1725 cc OHV Minx, Super Minx, High Comp CR 9.34 to 1, OHV Minx, Hunter, Hunter GT High Comp, CR...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 81.53908 | 72.39 | 46.99 | 23.8125 | 3.2102 | 2.85 | 1.85 | 15/16 |
1 cyl piston set 18517 for Austin - 1071cc OHV Mini Cooper S CR 9 to 1/1275 cc OHV Mini Cooper S CR 9.75 to 1/ Healey Sprite MkIV 9.75 to 1/1300GT CR 10.96 to 1 (Forged Piston)
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 70.612 | 58.6105 | 38.0365 | 20.6375 | 2.78 | 2.3075 | 1.4975 | 13/16 |
4 cyl piston set 18617 for Rover - 3528 cc OHV, Range Rover, V8, CR 8.25 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.8619 | 77.089 | 47.371 | 22.225 | 3.4985 | 3.035 | 1.865 | 7/8 |
4 cyl piston set 18679 for Ford - 1098 cc OHV Escort 1100, Export Cortina 1100, 6/8 cwt Van. CR 9 to 1, 2733E Engine
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18683 for Ford - 1298 cc OHV Escort 1300GT, Capri 1300 GT, 2735E Engine, CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18746 for Moskvitch - 1478 cc OHC 412 Saloon, 427 Estate, 434 Van, 412 Engine, CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 81.98 | 92 | 58 | 22 | 3.227559 | 3.622047 | 2.283465 | 0.866142 |
4 cyl piston set 18802 for Austin - 1798 cc OHV 1800, 1800 HL, 1800 MkII/MkIII CR 9 to 1, 1800S MkII CR 9.5 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.23733 | 61.1124 | 42.164 | 20.6375 | 3.15895 | 2.406 | 1.66 | 13/16 |
4 cyl piston set 19105 for Hillman - 875 cc OHC Imp, Super Imp, Husky, Low Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 70.2564 | 52.0573 | 26.67 | 15.875 | 2.766 | 2.0495 | 1.05 | 5/8 |
2 cyl piston set 19131 for Ford - 1969-71 1996 cc OHV Capri 2000GT, V4, CR 8.9 to 1. 1972 onwards 2994 cc OHV Capri, Consul GT, Granada, Granada GXL, 3 litre V6, CR 8.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 95.25 | 46.1391 | 23.8125 | 3.6869 | 3 3/4 | 1.8165 | 15/16 |
1 cyl piston set 19231 for Bedford - 3519 cc OHV 214 Engine 1 1/4 - 8 ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 85.725 | 46.1264 | 20.6375 | 3 3/8 | 3 3/8 | 1.816 | 13/16 |
6 cyl piston set 19298 for Ford - 4 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2994...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
1 cyl piston set 19299 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
1 cyl piston set 19320 for Austin, Mini, Morris - 1963-64 1071 cc OHV Mini Cooper S, CR 9 to 1. 1964/9 1275 cc OHV Mini Cooper S, CR 9.75 to 1. 1967 on, 1275 cc OHV 1300GT, CR 9.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 70.612 | 58.6105 | 38.0365 | 20.6375 | 2.78 | 2.3075 | 1.4975 | 13/16 |
4 cyl piston set 19472 for Chrysler - 1598 cc OHV Avenger 1600 GLS/TC. Low Comp CR 8.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.33536 | 75.7682 | 44.1198 | 23.8125 | 3.4384 | 2.983 | 1.737 | 15/16 |
4 cyl piston set 19603 for Toyota - 1077 cc KE10, KE16, K Engines, Corolla, Corolla Van. 1166 cc KE11, KE17, KE18, KE30, 3K-B/C/D, 3K Engines, Corolla, Corolla Coupe, Corolla Van. 4K Engine,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 75 | 36.1 | 18 | 2.952756 | 2.952756 | 1.42126 | 0.708661 |
4 cyl piston set 19724 for Vauxhall - 1159 cc OHV Viva De-Luxe, SL, CR 8.5 to 1 (Low Comp 7.3 to 1). 90 De Luxe, 90 SL, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7494 | 75.6412 | 37.6936 | 20 | 3.061 | 2.978 | 1.484 | 0.787402 |
4 cyl piston set 19740 for Toyota - 1968 cc 18R, 18RC Engines, Celica 2000, CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.5 | 85 | 39.8 | 22 | 3.484252 | 3.346457 | 1.566929 | 0.866142 |
4 cyl piston set 19906 for Triumph - 1998 cc OHC TR7, CR 8 to 1, USA Version
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.28684 | 70 | 34.1 | 23.8125 | 3.5546 | 2.755906 | 1.34252 | 15/16 |
2 cyl piston set 19929 for Yamaha - 247 cc RD250 Reed Valve Engine, CR 7 to 1 Two Stroke
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 54 | 70 | 33.1 | 16 | 2.125984 | 2.755906 | 1.30315 | 0.629921 |
6 cyl piston set 20108 for Ford - 1996 cc OHV Transit V4, CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 95.25 | 46.1391 | 20.6375 | 3.6869 | 3 3/4 | 1.8165 | 13/16 |
1 cyl piston set 20139 for Triumph - 1493 cc OHV 1500, CR 8.5 to 1. OHV 1500, 1500TC, Spitfire 1500, Dolomite 1500, 1500HL, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.6473 | 58.0898 | 32.6898 | 20.6375 | 2.8995 | 2.287 | 1.287 | 13/16 |
4 cyl piston set 20204 for Audi - 1093 cc. Audi 50/GLS/LS. CR 8/8.2 to 1, Pyrostrut design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 67.2 | 40.3 | 20 | 2.73622 | 2.645669 | 1.586614 | 0.787402 |
4 cyl piston set 20227 for Austin, Morris - 1993 cc Princess 2000HL/HLS, Morris OHC Ital 2000 HLS Saloon/Estate, Ambassador 2.0 HL/HLS, Montego 2.0 HL/HLS, 'O' Series Engine, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.4423 | 60.2488 | 35.30092 | 20.6375 | 3.3245 | 2.372 | 1.3898 | 13/16 |
1 cyl piston set 20297 for Rover - 2597 cc OHC 2.6 Litre CR 9.25 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 81 | 63.1 | 35.2 | 23.8125 | 3.188976 | 2.484252 | 1.385827 | 15/16 |
4 cyl piston set 20345 for Mitsubishi - 1597 cc 4G32R Engine, Colt Lancer/1600/G/SR, A53/C/V, Galant 1600, Galant GTO/ Galant Station Wagon/Galant FTO 1.6, Colt Celeste 1600 GT, Dodge Colt...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.9 | 70.5 | 33.5 | 19 | 3.027559 | 2.775591 | 1.318898 | 0.748031 |
4 cyl piston set 20397 for Austin, Morris - 1098 cc Austin A40 MkII 1100 OHV/Allegro 1100 De Luxe, Morris 1100/Minor 1000 OHV. 'A' Series Engine CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 58.0517 | 30.3276 | 15.86738 | 2.542 | 2.2855 | 1.194 | 0.6247 |
4 cyl piston set 20544 for Mazda - 1796 cc VB Engine, OHC, CR 8.6 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78 | 82.3 | 45.4 | 22 | 3.070866 | 3.240157 | 1.787402 | 0.866142 |
4 cyl piston set 20614 for Volvo - 4 Cyl, 1986 cc B20A, B20F Engines, OHV, 142, 142E, 144, 144 E, 145, 142 S, 144 S, 145 S, 144 DL, 145 DL, 144 GL, 1800 E, 1800 S, 1800 ES, CR 8.7 to 1. B20B...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.89 | 71 | 46.1 | 22 | 3.499606 | 2.795276 | 1.814961 | 0.866142 |
4 cyl piston set 20684 for Lada - 1294 cc OHC 1300, 1568 cc OHC 1600, Niva 1600, CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78.99 | 77.25 | 38.1 | 22 | 3.109843 | 3.041339 | 1 1/2 | 0.866142 |
4 cyl piston set 20888 for Volkswagen - 1984 cc 2 Litre transporter, LT28-281CH/283, CH285/CH; LT31-281CH/283, CH285/CH, LT35
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86.51 | 77.6 | 40.85 | 24 | 3.405906 | 3.055118 | 1.608268 | 0.944882 |
4 cyl piston set 21072 for Nissan - 3956 cc P/P40/PF Engines, Cabstar Bus, Carrier Truck, Patrol 4WD, Carrier Bus. CR 7.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.7 | 94.5 | 53.35 | 20.653 | 3.374016 | 3.720472 | 2.100394 | 0.81311 |
1 cyl piston set 21138 for Yamaha - YZ125 J
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56 | 56 | 32 | 16 | 2.204724 | 2.204724 | 1.259843 | 0.629921 |
1 cyl piston set 21262 for Vauxhall - 1598 cc 1.6N, 1.6S Engine, OHC Astra 1600L, GL, SR, Belmont 1600L, GL, GLS, Cavalier, L, GL, LX, SR, GLS. CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 72 | 40.05 | 23 | 3.149606 | 2.834646 | 1.576772 | 0.905512 |
4 cyl piston set 21776 for Suzuki - 970 cc F10A Engine, OHC Jimny SJ410/Q/V, 4WD, 110S40FK, 1000SJ40VC CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 2.57874 | 0 | 0 | 0 | |||
4 cyl piston set 22061 for Lada - 1568 cc 1600 Engine OHC Lada 1600, VAZ 2106, Lada/Shiguli 2107, CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78.99 | 77.25 | 38 | 22 | 3.109843 | 3.041339 | 1.496063 | 0.866142 |
4 cyl piston set 158809 for Petter - AV1, AVA1, AV2, AVA2, Series II, AH1, Diesel. Water Cooled Bore is 80 mm, Air Cooled is 80.101mm
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 106 | 63.5 | 30 | 3.149606 | 4.173228 | 2 1/2 | 1.181102 |
1 cyl piston set 199508 for Petter - PC Series, Diesel. 3" Bore for water cooled, 3.0013" for Air Cooled
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 84.9376 | 50.8 | 22.225 | 3 8.8817841970013E-16/2 | 3.344 | 2 | 7/8 |
1 cyl piston set 350026 for Petter - PAZI, Air Cooled, Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 92 | 55.042 | 27 | 3 8.8817841970013E-16/2 | 3.622047 | 2.167008 | 1.062992 |
4 cyl piston set 350051 for Ford - 4 cyl 2358 cc Transit 75/80/90/100/115/125/130/150/160/175/190, Vans 100, 150. York 2.4 litre. 3537 cc A Series. 6 cyl Parent Block Engine. Indirect Injection...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64472 | 108.0008 | 61.64834 | 28.99918 | 3.6868 | 4.252 | 2.4271 | 1.1417 |
4 cyl piston set 350178 for Volkswagen - 1471 cc Golf LD/GLD, 50 bhp., Diesel, CR 23.5 to 1, Passat LD/gld, Industrial Engine Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.51 | 76.83 | 44.93 | 22 | 3.012205 | 3.024803 | 1.768898 | 0.866142 |
1 cyl piston set 350226 for Ford - 158 cubic inches, 32D Engine 3 cyl, Dexta Tractor, Series 6Y, 2000, Series 7A, 2600, 233. CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 106.69778 | 134.112 | 75.2983 | 38.1 | 4.2007 | 5.28 | 2.9645 | 1 1/2 |
1 cyl piston set 350268 for Petter - PJ MkII, PJW Ser, Air and Water cooled Multi Cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 96.8756 | 105.9942 | 63.59906 | 30 | 3.814 | 4.173 | 2.5039 | 1.181102 |
1 cyl piston set 350310 for Petter - 304 cc Acw, 1W, 2, 2W Engines, 1 and 2 Cyl, CR 17 to 1, Diesel/
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 69.85 | 44.2468 | 22.225 | 3 8.8817841970013E-16/2 | 2 3/4 | 1.742 | 7/8 |
6 cyl piston set 350383 for Bedford - 4 cyl 3614 cc D/K//TJ/TKV Series 1 1/4 - 4 Ton Trucks. 6cyl 5420 cc 5-12 ton trucks
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 103.1748 | 118.237 | 71.501 | 34.925 | 4.062 | 4.655 | 2.815 | 1 3/8 |
1 cyl piston set 350422 for Land Rover - 2494 cc 12J Engine, 90, 110, Defender 110, Defender 130. Diesel, CR 21 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.424 | 86.3092 | 54.5846 | 30.1498 | 3.56 | 3.398 | 2.149 | 1.187 |
4 cyl piston set 360001 for Fiat - 1116 cc OHC 128, 128 Sport Coupe 1100, L1100, 128 Special 1100, 128 3P 1100, CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 72.3 | 35.3 | 22 | 3.149606 | 2.846457 | 1.389764 | 0.866142 |
1 cyl piston set 483506 for Lister - SR Series, Air Cooled Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9 | 103.1875 | 65.0875 | 29.36875 | 3 1/2 | 4 1/16 | 2 9/16 | 1 5/32 |
1 cyl piston set 583206 for David Brown - 3 cyl 2695 cc 880, 885. 4 cyl 3594 cc 995/996/1200/1210/1212. Direct Injection Diesel. CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 100.04552 | 105.5624 | 60.3758 | 31.75 | 3.9388 | 4.156 | 2.377 | 1 1/4 |
1 cyl piston set 665872 for Fiat - 125 Berlina, Engine type 125A CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 83.7 | 44.2 | 22 | 3.149606 | 3.295276 | 1.740157 | 0.866142 |
4 cyl piston set 666708 for Fiat - 1297 cc 131.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76 | 78.45 | 38.95 | 22 | 2.992126 | 3.088583 | 1.533465 | 0.866142 |
4 cyl piston set 668072 for Fiat, Iveco, Renault - 2445 cc Fiat/Iveco 8140.21 Engine, 1985/86; Daily Turbo id, 1986/90; Ducato 4x4 Turbo, Maxi Turbo id, Ducato Minibus Turbo. 1985 onwards; 35.10,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93 | 97.65 | 59.65 | 32 | 3.661417 | 3.844488 | 2.348425 | 1.259843 |
4 cyl piston set 11920 JP for Ford - 10h.p. 1172 cc SV Taunas 12M, Anglia, Prefect, Escort, Squire, 1600 Series
Used ran on engine once discounted to £250 + vat
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 74.678 | 45.34 | 2 1/2 | 2.940079 | 1.785039 | ||
