| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
Triumph
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.28866 | 74.3458 | 38.4556 | 20.6375 | 2.7279 | 2.927 | 1.514 | 13/16 |
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
Austin
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.09 | 93.6625 | 47.625 | 22.225 | 3.35 | 3 11/16 | 1 7/8 | 7/8 |
Bedford M type
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 85.725 | 41.275 | 20.6375 | 3 3/8 | 3 3/8 | 1 5/8 | 13/16 |
4 cyl piston set 2326 for Ford - 14.9h.p. AF, ABF, C.R. 5.2 to 1, Aluminium version of 2481
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.597 | 89.69375 | 48.41875 | 25.4 | 3.055 | 3 17/32 | 1 29/32 | 1 |
6 cyl piston set 3339 for Vauxhall - 16.9h.p. 2048cc Cadet, VY
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 67.5 | 77.7875 | 41.275 | 22.225 | 2.65748 | 3 1/16 | 1 5/8 | 7/8 |
4 cyl piston set 4607 for Scammell - 10h.p. 1292cc MH3, 3 Ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 67.865625 | 38.89375 | 15.875 | 2 1/2 | 2 43/64 | 1 17/32 | 5/8 |
6 cyl piston set 4823 for Essex - 16.9h.p. 2723cc Terraplane E78
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 67.46875 | 84.1375 | 46.0375 | 19.05 | 2 21/32 | 3 5/16 | 1 13/16 | 3/4 |
6 cyl piston set 5422 for Morris - 21h.p. 2916cc Twenty One, OJ, Series II
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 51 | 95.5 | 22 | 2.952756 | 2.007874 | 3.759843 | 0.866142 |
4 cyl piston set 5778 for Cadillac - V8 355E, 355D
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 118.665625 | 45.640625 | 22.225 | 3 3/8 | 4 43/64 | 1 51/64 | 7/8 |
6 cyl piston set 7371 for Gardner - 27.3h.p. M40, 046 2 to 5 ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 103.98125 | 54.76875 | 22.225 | 3 3/8 | 4 3/32 | 2 5/32 | 7/8 |
4 cyl piston set 7450 for Mercedes - 13.4h.p. 1697cc 170V, 170H M28
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.5 | 79.5 | 38 | 11 | 2.893701 | 3.129921 | 1.496063 | 0.433071 |
4 cyl piston set 7664 for Austin - 11.9h.p. 1535cc 12/4 C.R 6.2 to 1 4 cyl 1933-47, 17.9h.p. 2510cc fitted to 16h.p. chassis C.R 6.3 to 1, 6 cyl, Light 12/4, 8/10cwt 4cyl, 15cwt, Ambulance 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.342 | 79.375 | 38.1 | 15.875 | 2.73 | 3 1/8 | 1 1/2 | 5/8 |
6 cyl piston set 7672 for Austin - 13.9h.p. 1496cc Twelve Six, 12h/p/ 10cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.214 | 63.5 | 33.3375 | 14.2875 | 2.41 | 2 1/2 | 1 5/16 | 9/16 |
4 cyl piston set 7687 for Ford - 8h.p. Model Y, 5cwt, Tug, 40cwt, ring below pin
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56.642 | 61.11875 | 26.19375 | 17.4625 | 2.23 | 2 13/32 | 1 1/32 | 11/16 |
4 cyl piston set 7695 for Hillman - 9.8h.p. 1185cc Minx, Minx Magnificent, Aero Minx
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 76.99375 | 38.89375 | 16 | 2.480315 | 3 1/32 | 1 17/32 | 0.629921 |
4 cyl piston set 7765 for Morris - 10h.p. 1292cc Ten Four Series II, III
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 74 | 37.5 | 16 | 2 1/2 | 2.913386 | 1.476378 | 0.629921 |
6 cyl piston set 7787 for Austin - 16h.p. Export
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 76.2 | 38.1 | 15.875 | 2.57874 | 3 8.8817841970013E-16/2 | 1 1/2 | 5/8 |
6 cyl piston set 7804 for Morris - 16h.p. 2062cc Oxford
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 77 | 40.5 | 18 | 2.57874 | 3.031496 | 1.594488 | 0.708661 |
4 cyl piston set 7808 for Standard - 12h.p. 1608cc, C.R. 5.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 78.978125 | 39.290625 | 15.875 | 2.73622 | 3 7/64 | 1 35/64 | 5/8 |
4 cyl piston set 7819 for Rover - 10.8h.p. 21389cc Ten
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.5 | 40.084375 | 78.184375 | 15.875 | 2.61811 | 1 37/64 | 3 5/64 | 5/8 |
4 cyl piston set 7984 for Standard - 10h.p. 1267cc Flying Ten C.R. 6.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 73.025 | 38.1 | 19.05 | 2 1/2 | 2 7/8 | 1 1/2 | 3/4 |
6 cyl piston set 8107 for Commer - 20/70h.p.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 2.952756 | 0 | 0 | 0 | |||
4 cyl piston set 8112 for Standard - 8h.p. 1021cc, Flying Eight C.R 6.7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57 | 73.025 | 38.1 | 15.875 | 2.244094 | 2 7/8 | 1 1/2 | 5/8 |
6 cyl piston set 8282 for Vauxhall - 14h.p. 1781cc, J, C.R 6.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.5 | 2.42126 | 0 | 0 | 0 | |||
1 cyl piston set 8499 for Armstrong Siddeley - 14h.p. 1668cc
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 60.96 | 76 | 41 | 15.875 | 2.4 | 2.992126 | 1.614173 | 5/8 |
1 cyl piston set 8684 for Bedford - 20h.p. BYC, 12cwts C.R. 5.625 to 1. Aluminium Piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.025 | 77.7875 | 41.275 | 22.225 | 2 7/8 | 3 1/16 | 1 5/8 | 7/8 |
6 cyl piston set 8735 for Lanchester - 14.06h.p. 1809 cc Fourteen, Roadrider De Luxe, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.468 | 80.16875 | 44.45 | 17.77 | 2.42 | 3 5/32 | 1 3/4 | 0.699606 |
4 cyl piston set 8788 for Ford - 10h.p. 1172cc Prefect, long 4 ring piston, ring below pin
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.85 | 30.95625 | 17.4625 | 2 1/2 | 2 3/4 | 1 7/32 | 11/16 |
6 cyl piston set 8979 for Dodge - 28.35h.p. All 3 7/16" bore models after engine 42000. US Army T118-WF31. Types F G H J K Series B1 and B2, 64, 103, 105, 123, 125
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 95.25 | 50.8 | 21.828125 | 3 7/16 | 3 3/4 | 2 | 55/64 |
1 cyl piston set 9178 for Lanchester - 10h.p. 1203 cc Car Nos 15000 to 20050
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.05625 | 38.1 | 15.875 | 2 1/2 | 2 23/32 | 1 1/2 | 5/8 |
1 cyl piston set 9656 for Petter - A1, W1, Series II, 1 Cyl. 2LTA, 2AV, PA, PAW, Series II, 2 Cyl. PAV, Series II, 4 Cyl. C.I.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.0138 | 82.86 | 40 | 19 | 3.347 | 3.262205 | 1.574803 | 0.748031 |
1 cyl piston set 10056 for Petter - AV1,AV2, Series I, Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 116.5 | 63.5 | 30 | 3.149606 | 4.586614 | 2 1/2 | 1.181102 |
4 cyl piston set 10345 for Perkins - PA, PB, P4, 4192, 14.7h.p.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9254 | 3.501 | 0 | 0 | 0 | |||
4 cyl piston set 10931 for Hillman - 1265 cc Minx Mark IV, V, VI, VII, SV, Husky, MkI, CR 6.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.0875 | 73.92 | 39 | 17.4625 | 2 9/16 | 2.910236 | 1.535433 | 11/16 |
4 cyl piston set 11582 for Morris - 10h.p. 1140 cc Series M, SM, Ten Four
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 73.5 | 45 | 16 | 2 1/2 | 2.893701 | 1.771654 | 0.629921 |
4 cyl piston set 12199 for Land Rover - 1997 cc 2 Litre, CR 6.73 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.8 | 93.4212 | 61.6712 | 17.4625 | 3.062992 | 3.678 | 2.428 | 11/16 |
4 cyl piston set 12545 for Morris - 14h.p. 1818 cc Morris Series II and III, Fourteen Six, 'Q'
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.5 | 70 | 42.5 | 18 | 2.42126 | 2.755906 | 1.673228 | 0.708661 |
4 cyl piston set 12786 for Volkswagen - 1192 cc OHV: 1200, 15 cwt. Van, Kombi, Microbus, RWD Air Cooled, High Comp CR 7.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77 | 84 | 42 | 20 | 3.031496 | 3.307087 | 1.653543 | 0.787402 |
4 cyl piston set 13565 for Renault - 845 cc OHV Dauphine (Five Ring Design)
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 1473.2 | 64 | 30 | 14 | 58 1.4210854715202E-14/2 | 2.519685 | 1.181102 | 0.551181 |
1 cyl piston set 14502 for B & S - ZZP/23FB Air cooled
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 77.7875 | 42.8625 | 18.653125 | 3 8.8817841970013E-16/2 | 3 1/16 | 1 11/16 | 47/64 |
4 cyl piston set 15799 for Austin - 997 cc OHV Seven Cooper CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62.4205 | 63.2968 | 31.5468 | 15.875 | 2.4575 | 2.492 | 1.242 | 5/8 |
4 cyl piston set 16217 for MG - 1622 cc OHV MGA 1600 MkII, Magnetto Mk IV, High Comp CR 8.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.1873 | 76.99375 | 42.06875 | 19.05 | 2.9995 | 3 1/32 | 1 21/32 | 3/4 |
1 cyl piston set 16465 for Suzuki - 50 cc M15 Sportsman, M15D Sovereign, M12 Supersport, Two Stroke. CR 6.7 to 1. M30 Suzy, Two Stroke, CR 6.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 41 | 51.5 | 30.5 | 12 | 1.614173 | 2.027559 | 1.200787 | 0.472441 |
4 cyl piston set 17229 for Reliant - 598 cc OHV 3/25 from Enigine 88758
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 55.88 | 46.0375 | 22.225 | 14.2875 | 2.2 | 1 13/16 | 7/8 | 9/16 |
4 cyl piston set 17560 for Ford - 1298 cc OHV Escort 1300GT, Capri 1300 GT, 2735E Engine, CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 17929 for Triumph - 1970/71 1493 cc OHV, 1500 CR 8.5 to 1, 1972 1500 CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.6473 | 57.94375 | 32.54375 | 20.6375 | 2.8995 | 2 9/32 | 1 9/32 | 13/16 |
4 cyl piston set 18495 for Hillman - 1248 cc OHV Avenger, De Luxe, Super, CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78.6003 | 75.803125 | 44.053125 | 23.8125 | 3.0945 | 2 63/64 | 1 47/64 | 15/16 |
4 cyl piston set 18645 for Ford - 1098 cc OHV Escort 1100, Export Cortina 1100, 6/8 cwt Van. CR 9 to 1 Uprated 711M Engine
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
1 cyl piston set 18684 for Ford - 1599 cc OHV Cortina 1600, 1600GT, Capri 1600, 2737E Engine, CR 9 to 1. 1599 cc OHV Capri 1600GT CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
6 cyl piston set 18811 for Opel - 2490 cc 2.5 litre, Blitz CR 7.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87 | 87 | 45 | 23 | 3.425197 | 3.425197 | 1.771654 | 0.905512 |
6 cyl piston set 19132 for Ford - 2494 cc OHV Consul, Consul L, Granada, Granada GXL, 2.5 litre V6 CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 101.346 | 52.1716 | 23.8125 | 3.6869 | 3.99 | 2.054 | 15/16 |
4 cyl piston set 19298 for Ford - 5 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2994...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
6 cyl piston set 19300 for Ford - 1966 onwards 4 cyl 1996 cc OHV Corsair GT, Zephyr 4 MkIV, Corsair 2000, 2000E, Capri, 2000GT, 1972 onwards OHV Consul, Consul L, 2 litre V4 CR 10 to 1. 6 cyl 2994...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.996 | 46.1391 | 23.8125 | 3.6869 | 3.74 | 1.8165 | 15/16 |
4 cyl piston set 19354 for Austin - 1798 cc OHV 1800 MkII/MkIII Low Comp CR 8 to 1, 1800S MkII Low Comp CR 8.5 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.2513 | 61.0616 | 42.1132 | 20.6375 | 3.1595 | 2.404 | 1.658 | 13/16 |
4 cyl piston set 19565 for Mercedes - 1965/8 1988 cc 200, 110B2, O309B, M121 Engine. 1969 Onwards 2197 cc 220 M115 Engine. CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87 | 88 | 48 | 26 | 3.425197 | 3.464567 | 1.889764 | 1.023622 |
4 cyl piston set 19658 for Datsun, Nissan - 1595 cc L16 Engine. 1967-73; Bluebird 1600. 73-80; (P510). 73-80; Bluebird 160B (610, L610, LJ810, V610, VLJ810). 80-84; Bluebird 1.6 GL (TJ910,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83 | 78 | 38.1 | 21 | 3.267717 | 3.070866 | 1 1/2 | 0.826772 |
4 cyl piston set 19734 for Chrysler (France)Simca - 1812 cc OHC 180, Europa 160 GT, CR 9.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.7 | 87.1 | 49.06 | 24 | 3.452756 | 3.429134 | 1.931496 | 0.944882 |
2 cyl piston set 19750 for Volvo - 4 Cyl, 1986 cc OHV 142, 142E, 144, 144E, 145, 142S, 144S, 145S, 144DL, 145DL, 144GL, 1800E, 1800S, 1800ES, B20A, B20F, Engines, CR 8.7 to 1. B20B Engine, CR 9.5...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.89 | 71 | 46 | 22 | 3.499606 | 2.795276 | 1.811024 | 0.866142 |
1 cyl piston set 19914 for Ford - 1599 cc OHV Escort 1600, Sport 1600, Ghia 1600, 751M Engine, High Comp CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
2 cyl piston set 19969 for Suzuki - 2 Cyl 184 cc GT185A/B/C/EC, ET185K, GT185L, GT185M Two Stroke
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 49 | 60 | 31.1 | 12 | 1.929134 | 2.362205 | 1.224409 | 0.472441 |
4 cyl piston set 20128 for Land Rover, Rover - 2286 cc OHV Series II, IIA, III, 2 1/4 Litre, Rover 80, CR 7 to 1, Optional 4 Ring design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.4748 | 99.9236 | 58.5216 | 25.4 | 3.562 | 3.934 | 2.304 | 1 |
4 cyl piston set 20139 for Triumph - 1493 cc OHV 1500, CR 8.5 to 1. OHV 1500, 1500TC, Spitfire 1500, Dolomite 1500, 1500HL, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.6473 | 58.0898 | 32.6898 | 20.6375 | 2.8995 | 2.287 | 1.287 | 13/16 |
4 cyl piston set 20208 for Volkswagen - 895 cc Polo, Polo L, Derby, L, LX. CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 74 | 47.1 | 20 | 2.73622 | 2.913386 | 1.854331 | 0.787402 |
1 cyl piston set 20229 for Datsun, Nissan - A14 Engine; Datsun 1396 cc B210, Nissan 1397 cc Sunny 140Y Coupe, GL Estate, Violet 1.4 GL, California 210, Cherry, Pulsar. CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76 | 67.5 | 32.6 | 19 | 2.992126 | 2.65748 | 1.283465 | 0.748031 |
1 cyl piston set 20317 for Ford - 2551 cc 2.6 litre V6, 26M, 2600 S, RS2600, Capri 2600 RS/ GT, Granada L, GL, GXL, Ghia, S, GLS and Turnier, CR 8.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90 | 74.78 | 40.38 | 24 | 3.543307 | 2.944094 | 1.589764 | 0.944882 |
1 cyl piston set 20358 for Suzuki - 2 Cyl, 247 cc GT250M, A, B, C. 3 Cyl, 371 cc GT380 J, K, L, M, A, B
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 54 | 68.5 | 32.6 | 14 | 2.125984 | 2.69685 | 1.283465 | 0.551181 |
4 cyl piston set 20431 for Chrysler - 1294 cc OHV Alpine GL/Horizon GLS, 1442 cc OHV Alpine S/GLS. CR 9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.692 | 64.5 | 37.6 | 22 | 3.01937 | 2.53937 | 1.480315 | 0.866142 |
1 cyl piston set 20550 for Ford - 1298 cc OHV Escort 8 cwt Van, Capri 1300, Cortina 1300, Escort 1300, Popular 1300, Ghia 1300, Sport 1300, Fiesta 1300. 751M Engine, High Comp, CR 9 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
2 cyl piston set 20614 for Volvo - 4 Cyl, 1986 cc B20A, B20F Engines, OHV, 142, 142E, 144, 144 E, 145, 142 S, 144 S, 145 S, 144 DL, 145 DL, 144 GL, 1800 E, 1800 S, 1800 ES, CR 8.7 to 1. B20B...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.89 | 71 | 46.1 | 22 | 3.499606 | 2.795276 | 1.814961 | 0.866142 |
4 cyl piston set 20752 for Volvo - 1974/8 2127 cc B21A Engine, Carburettor version, 97/100bhp 242 DL, 244 DL, 245 L/GL/DL/T, CR 8.5 to 1. 1980 On B21E Engine, 103 bhp., for USA with fuel...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 92 | 71 | 46.1 | 24 | 3.622047 | 2.795276 | 1.814961 | 0.944882 |
1 cyl piston set 20979 for Suzuki - 100 cc GP100C/UC/N/UN, GP100D
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 50 | 60 | 31 | 14 | 1.968504 | 2.362205 | 1.220472 | 0.551181 |
4 cyl piston set 21076 for Leyland - 1695 cc 'O' Series Engine OHC, Sherpa 200/230/250/255 CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.4423 | 72.04964 | 42.09796 | 20.6375 | 3.3245 | 2.8366 | 1.6574 | 13/16 |
4 cyl piston set 21207 for Nissan - 1598 cc CA16 Engine, Stanza 1600, Violet 1600, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78 | 66.25 | 31.3 | 20 | 3.070866 | 2.608268 | 1.232283 | 0.787402 |
6 cyl piston set 21379 for Daimler, Jaguar - 4235 cc 6 cyl OHC Fuel Injection, Daimler Sovereign 4.2 Series III, Jaguar 420, E-Type, Mk X, XJ6 4.2, XJ6 Series III, CR 8.7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 92.075 | 85.48878 | 41.5036 | 22.23008 | 3 5/8 | 3.3657 | 1.634 | 0.8752 |
4 cyl piston set 21946 for Nissan - 1998 cc L20/A/P/S Engine. 1978 Bluebird. 81-83; Cedric CDX Sedan. 70-77; Fairlady. 66 On; Gloria. 72 On; Laurel. 81-84; Laurel Sedan CDX, GL, SGLHardtop GL. 68...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78 | 75 | 40 | 20 | 3.070866 | 2.952756 | 1.574803 | 0.787402 |
4 cyl piston set 23513 for Ford - 1297 cc Escort Popular/L, Fiesta Ghia/SX/LX, Orion L. BL13H (HCS) Engine, CR 9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.96 | 53.9 | 29.45 | 18.035 | 2.911811 | 2.122047 | 1.159449 | 0.710039 |
6 cyl piston set 169405 for Perkins - 5560 cc OHV R6, F340, Six 340S, 5.56 Litre, Diesel, CR 17.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 101.6 | 121.7676 | 74.2696 | 36.5125 | 4 | 4.794 | 2.924 | 1 7/16 |
1 cyl piston set 234415 for Lister - HA, HB, HW Series, Diesel. CR 15.2 to 1. Water Cooled diameter is 4", Air Cooled is 4.002
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 101.6 | 127 | 73.0885 | 36.5125 | 4 | 5 | 2.8775 | 1 7/16 |
1 cyl piston set 350030 for Perkins - V8.510 From Engine 510U2000, 8.36 litre, Direct Injection Diesel CR 17.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 107.95 | 122.174 | 77.7875 | 41.275 | 4 1/4 | 4.81 | 3 1/16 | 1 5/8 |
6 cyl piston set 350067 for Ford - 4D 240 cubic inches, D Series, 2701E Vertical, 2706E Inclined. 6D 360 cubic inches, D Series 2704E Vertical, 2709E Inclined. Diesel, CR 16.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 104.775 | 118.11 | 71.0311 | 34.925 | 4 1/8 | 4.65 | 2.7965 | 1 3/8 |
1 cyl piston set 350199 for Ford - 3/4 cyl 175/256 cubic inches, Series 6Y, 3000, 5000, Super Major Tractor/Dexta, Series 7A, 3600, 333, 5600. CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 106.69778 | 129.0066 | 70.1802 | 38.1 | 4.2007 | 5.079 | 2.763 | 1 1/2 |
6 cyl piston set 350227 for Ford - 6571 cc 401 Cu. In, 6 cyl Dexta Tractor, Series 6Y, 8000, Series 7A, 8600, 8700. CR 16 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 106.69778 | 126.9746 | 68.1228 | 38.1 | 4.2007 | 4.999 | 2.682 | 1 1/2 |
1 cyl piston set 350303 for Ford - 4196 cc 256 Cu.in 4 cyl Turbocharged, Series 6Y, 7000, Series 7A, 7600, 7700, Dexta Tractor, CR 16.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 111.77778 | 129.2606 | 70.3834 | 41.275 | 4.4007 | 5.089 | 2.771 | 1 5/8 |
6 cyl piston set 350333 for Perkins - 5800 cc T6354.4 6 Cyl Engine, CR 16 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 98.4758 | 107.8484 | 69.7484 | 38.1 | 3.877 | 4.246 | 2.746 | 1 1/2 |
4 cyl piston set 350387 for Nissan - SD20 Engines, 1991 cc, Cedric, Homer, Junior Wagon, KRSE20, Laurel 200D, Q140, VRE20, CR 20 to 1, and SD22 Engines 2164 cc, Caball, Cabstar, Caravan, Cedric,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83 | 96 | 48.057 | 26 | 3.267717 | 3.779528 | 1.892008 | 1.023622 |
4 cyl piston set 350484 for Austin, Perkins - 1994 cc Prima 80T Engine, Austin Montego 2.0DL, DSL, Turbo. Perkins T4.20 Marine Engine, CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.4423 | 77.12964 | 48.1203 | 28 | 3.3245 | 3.0366 | 1.8945 | 1.102362 |
1 cyl piston set 404112 for Lister - SL Series, Air Cooled, Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9625 | 103.1875 | 65.0875 | 26.9875 | 3 3/16 | 4 1/16 | 2 9/16 | 1 1/16 |
4 cyl piston set 498906 for Austin - 1489 cc 1.5Litre A60 Cambridge, J2M16 JU250, CR 23 to 1. Can use R17710 rings if required
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.0123 | 85.725 | 46.0629 | 25.4 | 2.8745 | 3 3/8 | 1.8135 | 1 |
6 cyl piston set 664278 for Fiat - 2279 cc OHV 2300, Engine Type 114B, CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78 | 85.3 | 42.3 | 22 | 3.070866 | 3.358268 | 1.665354 | 0.866142 |
4 cyl piston set 665946 for Fiat - 1438 cc 124 Coupe 2nd Series, 124 Sport, 125 2nd Series
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 81.45 | 41.95 | 22 | 3.149606 | 3.206693 | 1.651575 | 0.866142 |
4 cyl piston set 666708 for Fiat - 1297 cc 131.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76 | 78.45 | 38.95 | 22 | 2.992126 | 3.088583 | 1.533465 | 0.866142 |
1 cyl piston set 667199 for Fiat - 1301 cc 138A1000 Ritmo 65L/CL, Targa oro, Strada 65L, CL
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86.4 | 76.7 | 34.7 | 22 | 3.401575 | 3.019685 | 1.366142 | 0.866142 |
4 cyl piston set 668072 for Fiat, Iveco, Renault - 2445 cc Fiat/Iveco 8140.21 Engine, 1985/86; Daily Turbo id, 1986/90; Ducato 4x4 Turbo, Maxi Turbo id, Ducato Minibus Turbo. 1985 onwards; 35.10,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93 | 97.65 | 59.65 | 32 | 3.661417 | 3.844488 | 2.348425 | 1.259843 |
4 cyl piston set 798110 for Renault - 845 cc R4, R4L, R5L, R6L, R6 850, 8 Cwt.Fourgon Van
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 58 | 64 | 30 | 16 | 2.283465 | 2.519685 | 1.181102 | 0.629921 |
4 cyl piston set 11920 JP for Ford - 10h.p. 1172 cc SV Taunas 12M, Anglia, Prefect, Escort, Squire, 1600 Series
Used ran on engine once discounted to £250 + vat
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 74.678 | 45.34 | 2 1/2 | 2.940079 | 1.785039 | ||
4 cyl piston set 129.14.07 for Peugeot - 2304 cc XD2-XD2P-XD94 Engines, 504 GLD/Berline/Familiale, 505 GRD/SRD, J7 PX/PY/PZ, J9, CR 22.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 94 | 99.9 | 57.42 | 28 | 3.700787 | 3.933071 | 2.26063 | 1.102362 |
